1414 N4 PHSS Series 316 Stainless Steel Enclosures - NEMA 4X
Continuous Hinge, Clamped Cover |
| << Product Information << Corrosian Resistant Enclosures << |
|
| Application |
|
- Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures.
- Provides protection where equipment may be hosed down or otherwise be very wet, or in specific applications where corrosion may be a problem.
|
| |
| Standards |
- UL 508 Type 3R, 4, 4X, 12 and 13.
- CSA Type 3R, 4, 4X, 12 and 13.
- Complies with
- NEMA Type 3R, 4, 4X, 12 and 13.
|
| |
| Construction |
- Formed from 14 gauge Type 316 stainless steel without knockouts, cutouts or holes.
- Smooth, continuously welded seams.
- Welded brackets provide for enclosure mounting.
- Continuous stainless steel hinged cover is secured with stainless steel clamps and screws.
- Oil resistant gaskets are permanently secured.
- All models include a removable 14 gauge inner panel.
- Tapped studs are provided for mounting inner panels.
- A bonding stud is provided on the door and a grounding stud is provided in the enclosure.
|
| |
| Finish |
- Cover and enclosure are natural stainless steel with a smooth brushed finish.
- Removable inner panel is finished in white powder coating.
|
| |
| Accessories |
|
|
|
Back to Top |
 |
| |
| Part No. |
A |
B |
C |
Panel Size |
F |
G |
H |
J |
L |
Cover
Dimensions |
T |
V |
Y |
Ship Wt.
(lbs)
w/ Panel |
| D |
E |
| 1414N4PHS16C4 |
6 |
4 |
4.0 |
4.88 |
2.88 |
3.50 |
6.75 |
2 |
3.6 |
7.5 |
6.31 |
4.31 |
3 |
0.31 |
0.56 |
5 |
| 1414N4PHS16E |
6 |
6 |
4.0 |
4.88 |
4.88 |
3.50 |
6.75 |
4 |
3.6 |
7.5 |
6.31 |
6.31 |
5 |
0.31 |
0.56 |
6 |
| 1414N4PHS16G |
8 |
6 |
3.5 |
6.75 |
4.88 |
3.00 |
8.75 |
4 |
3.1 |
9.5 |
8.31 |
6.31 |
5 |
0.25 |
0.63 |
6 |
| 1414N4PHS16I |
10 |
8 |
4.0 |
8.75 |
6.88 |
3.50 |
10.75 |
6 |
3.6 |
11.5 |
10.31 |
8.31 |
7 |
0.25 |
0.63 |
10 |
| 1414N4LPHS16K |
12 |
10 |
5.0 |
10.75 |
8.88 |
4.50 |
12.75 |
8 |
4.6 |
13.5 |
12.31 |
10.31 |
9 |
0.25 |
0.63 |
15 |
| 1414N4PHS16L6 |
12 |
12 |
6.0 |
10.75 |
10.88 |
5.50 |
12.75 |
10 |
5.6 |
13.5 |
12.36 |
12.31 |
11 |
0.25 |
0.63 |
20 |
| 1414N4PHS16M6 |
14 |
12 |
6.0 |
12.75 |
10.88 |
5.50 |
14.75 |
10 |
5.6 |
15.5 |
14.31 |
12.31 |
11 |
0.25 |
0.63 |
21 |
| 1414N4PHS16O6 |
16 |
14 |
6.0 |
14.75 |
12.88 |
5.50 |
16.75 |
12 |
5.6 |
17.5 |
16.31 |
14.31 |
13 |
0.25 |
0.63 |
26 |
|
| |
|
