PF Filter Fans
<< Product Information << Climate Control <<

Download PDF



Description
  • This line of fans provides innovative technology for fan cooling and pressurizing of industrial cabinets. A high quality filter fan provides an economical method of ensuring your enclosure does not overheat.
  • Filtered passive ventilation can be provided by an exhaust filter for either convection cooling or in combination with a fan in forced air cooling.
  • The slim-line design of this fan line is unique, when installed, the front louvered grill protrudes less than one quarter inch. The attractive grill maintains the sleek aesthetics of an enclosure system.
Standards
  • UR, CUR and CE.
  • Built to IP54 standards (except PF1000/PFA1000 - IP43 standards).
  • Maintains NEMA 12 integrity of enclosure.
  • Fan CSA Listed.
Features
  • Available in 115V and 230V versions
  • High performance fan motors with finger guards.
  • ABS-FR grills (except PF1000 Series which is polystyrene FR).
  • Durable, reusable filter mat.
  • Grills are black allowing for a complementary match to all cabinet colors.
  • Integral gasket to seal against enclosure. (except PF1000 - use PFG1000)
Easy Installation
  • The patented "Click and Fit" system allows for rapid filter fan and exhaust filter installation without screws.
  • After using the convenient cutout template (provided with every unit), the fan and/or exhaust filter just snaps into the opening.
Options
  • Reverse flow (exhaust) available on 5,6,7000 models
Accessories

Back to Top
Part No.
Voltage
Free Flow Air Delivery (CFM)
Air Delivery w/Exhaust (CFM)
Max. Static Pressure (Pa)
Filter Density (g/m²)
Filtering Level
Sound Level (dB)
Connector Type
Ambient Temp. °F Max/Min
Comparable IP Standard
Ship Wt. lbs
PF1000
 115 16 10 29 150 73% 39 2 - 12"
wires		 140/14 IP43 1.5
PF2000
 115 38 28 69 150 73% 49 terminal strip 122/14 IP54 2
PF2500
 115 89 62 57 150 73% 55 terminal strip 122/14 IP54 4
PF3000
 115 169 142 89 150 73% 55 terminal strip 122/14 IP54 4
PF5000
 115 324 249 205 150 73% 69 terminal strip 122/14 IP54 7
PF6000
 115 410 295 225 150 73% 71 terminal strip 122/14 IP54 8
PF7000
 115 506 368 158 150 73% 72 terminal strip 122/14 IP54 8
PF1000230
 230 16 10 29 150 73% 39 2 - 12"
wires		 140/14 IP43 1.5
PF2000230
 230 38 28 69 150 73% 49 terminal strip 122/14 IP54 2
PF2500230
 230 89 62 57 150 73% 55 terminal strip 122/14 IP54 4
PF3000230
 230 169 142 89 150 73% 55 terminal strip 122/14 IP54 4
PF5000230
 230 324 249 205 150 73% 69 terminal strip 122/14 IP54 7
PF6000230
 230 410 295 225 150 73% 71 terminal strip 122/14 IP54 8
PF7000230
 230 506 368 158 150 73% 72 terminal strip 122/14 IP54 8
