Drawing Downloads
| Additional Downloads |
|---|
| Specification Sheet |
| Plastic Chemical Resistance Statement 10-2023 |
| Part Attributes | |
|---|---|
| Part Number | 1556GAWH |
| Series | Modern General Purpose Enclosures (1556 Serie) |
| Short Description | FRABS WALL MOUNT/ IOT ENCL |
| Long Description | FRABS DESKTOP/WALL MOUNT/IOT INDOOR ENCLOSURE |
| Size L x W x H |
6.3 in x 7.87 in x 2.76 in (160 mm x 200 mm x 70 mm) |
| Shipping Weight | 0.66 lbs (0.30 kg) |
| UNSPSC | 39121301 |
| UPC | 623980667317 |
| REACH Compliant | Yes (more info...) |
| RoHS Compliant | Yes (more info...) |
| Packaging Type | shrink wrap |
| Material | ABS Plastic |
| Color | White |
| Flame Rating | UL94 V-0 |
| IP Rating | IP54 |
| Product Category | Enclosures |
| Max. P.C. Board Length (mm) | 185 |
| Max. P.C. Board Width (mm) | 142 |
| Replacement Parts and Accessories | |
|---|---|
| 1421T6CL | PKG OF 24 CLEAR RUBBER FEET (Rubber Feet) |
| 1556GPL | Aluminum Panel (Inner Panel) |
| PMB110127KIT3 | 7" pole mount kit for 1556, 1557 (Pole Mount Kit 7") |
| PMB110127KIT4 | 15" pole mount kit for 1556, 1557 (Pole Mount Kit 15") |
| SC526-50 | #6 x 1/4" SELF-TAP PLASTITE, PAN HEAD, STEEL, ZINC PLATE (PCB Screws) |
| SC527-50 | hardware - package of 50 replacement screws (Lid Screws) |
| SC556-50 | #8x3/8" SS SELF-TAP (Mounting Foot Screws) |
