| Part Attributes | |
|---|---|
| Part Number | 1591TBG |
| Series | Boîtiers en plastique ABS tout usage avec guide-cartes (Série 1591) |
| Short Description | ABS PLASTIC |
| Long Description | enclosure - plastic |
| Size L x W x H |
4.72 in x 3.16 in x 2.32 in (120 mm x 80 mm x 59 mm) |
| Shipping Weight | 0.29 lbs (0.13 kg) |
| UNSPSC | 39121301 |
| UPC | 623980793917 |
| REACH Compliant | Yes (more info...) |
| RoHS Compliant | Yes (more info...) |
| Packaging Type | shrink wrap |
| Material | ABS Plastic |
| Color | Beige |
| Flame Rating | UL94 V-0 |
| IP Rating | IP54 |
| Product Category | Enclosures |
| Type | project box, general purpose |
| Replacement Parts and Accessories | |
|---|---|
| 1591MS100 | replacement machine screws for 1591 series with brass bushings, 100-pack (Lid Screws) |
| 1591TC | lid - clear polycarbonate, made to fit 1591T enclosures (Clear Lid Accessory) |
