Features:
- Rack rails are constructed in 12-gauge welded steel. Base angles are constructed in 1/4" steel plates.
- 19" EIA compliant 10-32 double-tapped rails.
- Includes marked rack unit dividers to aid in equipment mounting.
- Don't forget to order your Mounting Hardware.
- The side of the mounting rails included ganging and accessory mounting holes.
- Two (2) pairs of 5/8" spaced 10-32 threaded ground studs are integrated into the rails. Stud pairs are conveniently located across from each other inside the rail channel. For added convenience, a pair is located near the top of the rack, while the other pair is located on the lower side.
- UL Listed 2416 load rated for up to 1,000 lbs (453 kg). Static Load tested to 4,000 lbs (1,814 kg).
- Finished in smooth RAL9005 black powder paint.
- Rails and base are packaged in cardboard to prevent freight damage.
- TAA-compliant for GSA Schedule purchases.
- RoHS Compliant.
- Manufactured in North America within an ISO 9001:2015 certified facility.
Part of the Rack Basics® line of economy rack solutions.
Gallery
Accessories
-
High-Density Vertical Finger Manager with Slam-Latching Door
-
Vertical Finger Cable Manager with Door
-
Vertical Rack Cable Manager with Door
-
Vertical Cable Manager Extensions
-
Top Wire Management
-
Horizontal Ring Cable Manager
-
Horizontal Finger Cable Manager
-
Rack Panels
-
Universal Rack Shelf
-
Two Post Mounting Adjustable Shelf
-
Two Post Variable Depth Shelf
-
Two Post Centered Shelf
-
Two Post Mounting Keyboard & Equipment Shelf
-
Two-Post Extension Support Bracket
-
2-Post Rack Low Profile Dolly
-
Open Frame Rack and Rack Cabinet Joining Kit
-
Rack Isolation Kit
-
Grounding & Bonding
-
10-32 Mounting Hardware
-
PDUs and Outlet Strips
-
Rackmount Adjustable Angle Bracket
Part Details
Click Part No, below, for details (e.g., Product drawings, assembly instructions, ship weight)
Units shown: inch. Switch units to: mm
Part No. | Overall Dimensions | Rack | Mounting Dimensions | Optional Vertical | |||
---|---|---|---|---|---|---|---|
Height | Width | Depth | Units | Height | Width | Cable Manager | |
RB-2P24 | 48.12 | 20.46 | 15.00 | 24U | 42.16 | 19.00 | RB-VCM24 |
RB-2P77 | 83.12 | 20.46 | 15.00 | 44U | 77.12 | 19.00 | RB-VCM44 |
RB-2P84 | 90.12 | 20.46 | 15.00 | 48U | 84.16 | 19.00 | RB-VCM48 |
Similar Products
Data subject to change without notice.
