Legacy Hammond Modular Racks 1469 Serie

Features

• Modular all welded 14 ga. formed steel frame with open sides.
• Removable louvered rear door, with square corners on concealed pin hinges with flush keyed lock (1427 B).
• Rack and dress panels have a modern angular appearance.
• May be joined to companion unit with six conveniently supplied bolts to form sturdy equipment housings.
• One set of 2 vertical 10 ga. panel rails drilled and tapped for 10-32 screws on standard EIA/RETMA rack spacing of 0.5-1.25" are fully adjustable on horizontal Amhal struts.
• Two adjustable 12 ga. Z rails mounted on Amhal struts.
• Two 0.75in x 1in conduit knock out provided in flange below rear door.
• Cut out in bottom 9x11" for cable or conduit entrance with bolted coverplate.
• Durable baked grey hammerlin enamel finish.
• Two stainless steel vertical dress trims covering panel screws and one horizontal top dress trim.
• One set of 8 wiring clips — 4 each front and rear.
• Corner wedge units have full height with removable rear cover-plates.

Please note that the 1469 series was discontinued over twenty (20) years ago and replacement parts are no longer available. Please consider our C2 or C4.
