| Additional Downloads |
|---|
| Specification Sheet |
| Part Attributes | |
|---|---|
| Part Number | R133-092-000 |
| Series | Étanchéité grâce à un charnière intégrée (Série R133-134) |
| Short Description | aluDOOR HINGED LID-RECESS |
| Long Description | enclosure - diecast aluminum |
| Size L x W x H |
6.3 in x 3.54 in x 2.76 in (160 mm x 90 mm x 70 mm) |
| Shipping Weight | 1.54 lbs (0.70 kg) |
| UNSPSC | 39121301 |
| UPC | 623980018560 |
| REACH Compliant | Yes (more info...) |
| RoHS Compliant | Yes (more info...) |
| Packaging Type | box |
| Material | Aluminum (Die-Cast Alloy) |
| Color | Dark gray |
| IP Rating | IP69K |
| Product Category | Enclosures |
| Type | Thick Wall, Water-Tight |
| NEMA Rating | 1, 4, 4X, 12 & 13 |
| Max. P.C. Board Length (mm) | 118.5 |
| Max. P.C. Board Width (mm) | 78.5 |
